Self-Clinching B BSBlind Self-clinching Nuts

简体 | 繁體 | FastenerExpo |

Same specifications, different dimensions for other parts.

Note: No model available for the selected specifications, borrowing for presentation.Self-Clinching B BS

Self-Clinching B BS

Unit: mm/inch

Self-Clinching B BS Blind Self-clinching Nuts

Unit: mm/inch

Find suppliers

Download

Self-Clinching B BS

Download this CAD model

Self-Clinching B BS Blind Self-clinching Nuts

For Nominal Thread Diameter

4#

P
PP
k₁	max
D	max
d₁	max
d_k	Nominal Size
	max
	min
b	min
L	max
L₁	Nominal Size
	max
	min
Recommend Hole Size	min=nominal size
Recommend Hole Size	max
Sheet Thickness	min
Code	steel
Code	stainless steel

-
40
0.038
0.150
0.165
0.250
0.260
0.240
0.210
0.335
0.380
0.390
0.370
0.166
0.169
0.040
B
BS
