GB /T 16674.2 (R) - 2016Hexagon Bolts With Flange With Metric Fine Pitch Thread - Small Series - Type R

简体 | 繁體 | FastenerExpo |

(Non-preferred) dimensions in parentheses.

GB /T 16674.2 (R) - 2016

Unit: mm

GB /T 16674.2 R - 2016 Hexagon Bolts With Flange With Metric Fine Pitch Thread - Small Series - Type R

Unit: mm

Find suppliers

Download

GBT16674.2-s_M8x1X40

Download this CAD model

GB /T 16674.2 R - 2016 Hexagon Bolts With Flange With Metric Fine Pitch Thread - Small Series - Type R

Thread Size
d

M8

P		Fine thread
		Fine thread
b		L≤125
		125＜L≤200
		L＞200
c		min
d_a		Type F	max
		Type U	max
d_c		max
d_s		max
		min
d_u		max
d_w		min
e		min
k		max
k₁		min
f		max
r₁		min
r₂		max
r₃		max
		min
r₄		Ref.
s		max
		min
V		max
		min

1
-
22
28
-
1.2
9.2
10
17
8
7.78
8.8
14.9
10.95
8.5
3.8
2.1
0.4
0.5
0.36
0.16
5.7
10
9.78
0.25
0.10

thousand-piece steel weight≈kg

18.34

Thread Lengthb

22
