Click Specification

Same specifications, different dimensions for other parts.

Unit:mm

Turnbuckle

YJT 8050

Display drawing:

标准YJT 8050 YJT8050 8050YJT Turnbuckle

Thread Size

M8

M8

M8

M8

M10×1.25

M10×1.25

M10×1.25

M10×1.25

7/16
-20

7/16
-20

E	+0.1
F	+0.1
d_k	Ref.
L	Ref.
D	Ref.
H	±0.3
c	Ref.
torque at failure, N·m
minimum ejector force, N
minimum detachment force, N
minimum load capacity, N

13	13	13	13	17	17	17	17	16	16
11	11	11	11	15	15	15	15	16	16
20.6	16.6	16.6	16.6	20.6	20.6	20.6	20.6	23.6	23.6
47	53	68	38	33	39.5	53	53	37	50
12.5	12.5	12.5	12.5	16.4	16.4	16.4	16.4	17.4	17.4
42	50	65	35	30	36.5	50	50	34	47
2.5	2	2	2	2	2.5	2.5	4.5	2.2	2.2
21	21	21	21	56	23	23	23	21	21
2500	2500	2500	2500	2500	2500	2500	2500	2500	2500
30000	20000	20000	20000	20000	30000	20000	20000	30000	30000
38100	38100	38100	38100	67300	67300	67300	67300	56000	56000
