DIN 137 (B) - 1994Wave Spring Washers

| 简体 | 繁體 |

DIN 137 (B) - 1994

Unit: mm

DIN 137 B - 1994 Wave Spring Washers

Unit: mm

Find suppliers

Download

DIN 137B_3

Download this CAD model

DIN 137 B - 1994 Wave Spring Washers

Nominal Diameter

3

d	min
d	max
d_c	Nominal Size
	max
	min
h	Nominal Size
	max
	min
H	max
H	min
per 1000 units ≈ kg	≈

3.2
3.5
8
8.45
7.55
0.5
0.55
0.45
1.6
0.8
0.166
